Video Wall / 55inch Did Lcd Screen Video Wall With Snb Tv Lcd Display Panel Video Wall
Description:
1. Splicing mode optional
The splicing wall uses the whole steel structure,with multi choices,meeting the visual effect for different occasions.
2. Screen HD: High definition, high brightness,color saturated and
3. Video wall display function is changeable
With function of single screen display,whole screen display,any combination display,
image roam,image stack, etc.
4. Flexible parameter settings:
The same color and brightness for whole video wall
5. Long service life, low maintenance cost
Over 6000 hours of service life, no need to replace the material equipment, maintenance cost is very low.
6. Environmental and health
Give out little heat, no radiation, no flicker,not to hurt the eyes,contain no harmful substances (such as lead, mercury, cadmium, chromium, etc.)
Features :
Branded LG/SAMSUNG/AUO industrial panel, supports 24 hours continuously playing
Full hardware structure, no CPU and operating system
Easy installation, only fix them together by metal bracket
Easy to operating, can operate system together with software flexible, we offer free software
Supports RS-232 serial ports remote control
Supports multiple signal input: BNC, YPbPr, VGA, HDMI, DVI and RS232
Images are displayed smoothly and naturally without time delay and tailing and image quality is quite smooth
Supports 10 x 10 pieces panels splice
Easy maintenance, if one unit is going bad, only replace it with a new one
Wireless control: common solution
The PC needs to connect LCD video wall with RS232 cable
And distance should be within 10m
The longer the cable, the weaker the signal
Now wireless control no need to worry about how to hide the cable between the PC and the distance is within Wi-Fi range
The new solution also supports multiple PCs to control LCD video wall
Supports multiple user management
Comes with 2xDVI inputs and supports two full HD signals at the same time. The common solution with one DVI input only, it requires a PC of matrix if two DVI inputs needed for the project, then the cost will increased
Supports setup screen timer and memory function after cutting off power
Scene management: users can save and preset the scene that want to display and can setup the scene interval in turn time
Accessories: RS232 convertor, RJ45 convertor, VGA cable, RJ45 cable, power cable, remote controller and software
technological Parameters:
| Model No. | JB/H53-LG |
| Panel Size | 55" |
| Max resolution | 1920X1080 |
| Screen Size [inch/cm] | 55 inch |
| Panel Technology | S-PVA TFT with direct white LED backlights |
| Aspect Ratio | 16:9 |
| Color | 8Bit,16.7M |
| Visual Angle (H/V) | 178°/178° |
| Response Time | <=10ms |
| Life(hrs) | >60,000(hrs) |
| Input and output | |
| DVI | 1 |
| HDMI | 1 |
| D15-RGB Input(VGA) | 1 |
| RJ45 | 2 |
| Composit video input(AV) | 2(2xBNC) |
| Composit video input | 2(2xBNC) |
| Split screen | Support picture in picture(PIP/POP/PAP) |
| Power supply | AC100V~240V |
| Maximum power consumption | 230W |
| Standby comsuption | <=3W |
| Temperature | |
| Working temperature | 0℃~50℃ |
| Working Humidity | 20%~80% |
| Dimension | 121.5*68.6cm |
Our Services
1. Reply your enquiry in 24 working hours.
2. Experienced staffs answer all your questions in professional and fluent English.
3. Customized design is available. OEM&ODM are welcome.
4. Exclusive, considerate and unique solution can be provided to our customers by our well-trained and
professional engineers and staffs.
5. Special discount and protection of sales area provided to our distributor.
6. 1 year warranty for the products.
Trade terms:
1. Price: Price coveres cost of controller &software,based on EXW Factory Price term
2. Lead time:within 5-15working days after payment.its depend on customer quantity
3. Payment terms:T/T,Western union
Installment Design:
Display Way:
Screen Design:
Product Tags:
|
|
High Definition 1920X1080 Flexible LED Screen , 55 Inch Large Video Wall DID Panel Images
|
