Fast Installation SMD 2427 4mm Full HD LED Video Wall Display System 1300Nit
Features:
1. New cabinet design without fan, good heat dissipation, concise, slim and light weight.
2. Display of stunning picture with stable performance, no ripples or black image.
3. Die-casting aluminum cabinet , latest optimized locking system , solid , easier and faster to operate.
4. Multi function , used as waterproof dance floor with surface mask and HD outdoor screen without mask.
High Brightness, Greating Stunning Color
5. Seamless connection, superior color uniformity and stunning image quality, without black gap line on connection and
information missing.
6. Foldable cabinet hander, well design of engonomics, easier dismantle, faster and comfortable operation.
7. Multi function idea for standing HD screen and dance floor display.
8. Waterproof front and back , idea for both indoor and outdoor rental.
9. High brightness and small pitch , delivering vivid video image.
10. Mask is easy to remove and install , anti-split and anti-scratch.
11. Solid CNC die-casting cabinets, surface overtakes 3 tons weight.
12. No extra fixing bar needed on flooring, easy and fast assemble.
Basic promise from JB:
A: Full automatic production to control our high quality, best color consistency and get better performance.
B: Energy saving, low power consumption and long lifespan 10,000 hours (about 10 years).
C: We guarantee that the equipment we provide are brand new, complete and unused.
D: Good heat dissipation capability and high waterproof because of the unique design of vent fan (like shutter).
E: Our quality control throughout every process from materials-production- test-package-delivery(led lamp, module.
Data Sheet:
| Modle No. | JB/3.91-R |
| Pixel Pitch | 3.91mm |
| Pixel Density | 65536dots/m² |
| Brightness | ≥1000-1300nit |
| LED Encapsulation | SMD2427 |
| Drive Mode | 1/13 scan |
| Cabinet Resolution | 128*128 dots |
| Cabinet Weight | ≤9KG |
| Max Pqwer Consumption | ≤680w/m² |
| Average Power Consumption | ≤340w/m² |
| Best Viewing Angle | H:160° V:120° |
| Refresh Rate | <1920Hz |
| Grey Scale | 14-16bit |
| Best Viewing Distance | 1.5-50m |
| Frame Rate | 60Hz |
| Drive IC | MBI5020 |
| Module Size | 125*250mm |
| Cabinet Size(W*H*D) | 500*500*86mm |
| Pixel Configuration | 1R1G1B |
| Color Temperature | 6500-9500k |
| Protection Level | IP31 |
| Cabinet Material | Die-casting Aluminum Alloy Cabinet |
| Operation Voltage | 220v/50Hz,110v/60Hz |
| Working Humidity | 10%-90% |
| Working Temperature | -20ºC--+50ºC |
| Video Signal | RF,S-Video,RGB,RGBHV,YUV,YC,COMPOSITION,etc. |
